| الاسم التجاري: | HongCe |
| رقم الطراز: | HC-A519-2 |
| الـ MOQ: | 1 مجموعة |
| السعر: | Negotiatable |
| شروط الدفع: | خطاب الاعتماد، تي/تي، د/ف |
| القدرة على التوريد: | 10 مجموعة لمدة شهر |
| Specification | Parameter |
|---|---|
| Drive Method | Servo Motor |
| Test Load | 4.91N, 9.81N, 14.72N |
| Bending Angle | 135°±2° on each side (can be any angle from 135° to 0 to 135°, single-sided and double-sided bending resistance) |
| Specimen Size | 15mm*150mm, specimen thickness less than 1.25mm |
| Test Speed | (175±10) r/min (speed can be set arbitrarily from 0 to 175±10 r/min) |
| Folding Head Width | 19±1mm |
| Folding Edge Radius | 0.38±0.02mm (replaceable) |
| Folding Head Gap Distance | 0.25mm/0.5mm/0.75mm/1.0mm (other gaps can be customized) |
| Counter | 0~999999 times, automatic stop |
| Dimensions | 421*357*526mm (L*W*H) |
| Display Method | Touchscreen display |
| Weight | Approximately 30KG |
| Power Supply | 1∮, 220V, 50HZ, 1A |
| Total Power Consumption | Approximately 500W |
| Main Test Item | Folding Endurance Test of Paper Fiber Materials |
